We are the only company in the world specialized in the design and production of Submerged Burners Melters (SBM)
Large contact area between flame and melt bubbles - volumic melting
Intense heat exchange between flame and melt - specific pull rate 20 t/day/m2
Intensive mixing of the melt - chemical homogeneity and fast transition from one glass composition to another
Low emission of NOx (2 times less than in conventional furnaces)
Good melting efficiency - average gas consumption 1,6 MWh/t of melt (can decrease until 1,2 MWh/t)
Wide range of granulometry of the batch - pieces of 50-70 mm down to the dust fraction
Able to melt very wet waste even with metal contamination
Compact size (5 times smaller than a conventional furnace of the same capacity) - only 4 m2 for 80 t/day pull rate
Ability to work in "On - Off" mode - needs about 2-3 hours to start or stop this furnace
Cheaper than standard flame furnace - fully equipped SBM smelter for 80 t/day costs less than 3 MEUR
Long service life - expensive ceramic refractories are not used in this furnace
If necessary, SBM smelter can be completely disassembled and assembled elsewhere
Very homogeneous melt at the exit of furnace
Pull rate up to 80 t/day per furnace
Lower initial investment cost
Possibility to work in start and stop mode
Quick switch from one product to the other
Our SBM furnace can be disassembled and redeployed
Small footprint - about 4 m2 for 80 ton/day production
Porous melt at the exit of furnace - best dissolution of silicate glass in autoclave
Batch large granulometry - from pieces of 50-70 mm to the dust fraction
